Network Router User Manual
Table Of Contents
- Router Platform User Interface Reference
- NAT Policy Page
- Router Interfaces Page
- Advanced Interface Settings Page
- AIM-IPS Interface Settings Page
- Dialer Policy Page
- ADSL Policy Page
- SHDSL Policy Page
- PVC Policy Page
- PPP/MLP Policy Page
- AAA Policy Page
- Accounts and Credential s Policy Page
- Bridging Policy Page
- Clock Policy Page
- CPU Policy Page
- HTTP Policy Page
- Console Policy Page
- VTY Policy Page
- Secure Shell Policy Page
- SNMP Policy Page
- DNS Policy Page
- Hostname Policy Page
- Memory Policy Page
- Secure Device Provisioning Policy Page
- DHCP Policy Page
- NTP Policy Page
- 802.1x Policy Page
- Network Admission Control Policy Page
- Logging Setup Policy Page
- Syslog Servers Policy Page
- Quality of Service Policy Page
- BGP Routing Policy Page
- EIGRP Routing Policy Page
- OSPF Interface Policy Page
- OSPF Process Policy Page
- RIP Routing Policy Page
- Static Routing Policy Page
Appendix K Router Platform User Interface Reference
OSPF Process Policy Page
K-244
User Guide for Cisco Security Manager 3.2
OL-16066-01
Navigation Path
Go to the OSPF Process Policy Page, page K-243, then click the Setup tab.
Related Topics
• Defining OSPF Process Settings, page 15-193
• OSPF Process Page—Area Tab, page K-247
• OSPF Process Page—Redistribution Tab, page K-249
• OSPF Interface Policy Page, page K-236
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
Table K-111 OSPF Process Setup Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Process ID The process ID that identifies the OSPF routing process to other routers.
Passive Interfaces The interfaces that do not send out routing updates.
Add button Opens the OSPF Setup Dialog Box, page K-245. From here you can define
an OSPF process.
Edit button Opens the OSPF Setup Dialog Box, page K-245. From here you can edit the
selected OSPF process.
Delete button Deletes the selected OSPF processes from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit icon on the toolbar.
