Appendix K Router Platform User Interface Reference
EIGRP Routing Policy Page
K-230
User Guide for Cisco Security Manager 3.2
OL-16066-01
Note You can access the EIGRP Interfaces tab only after defining at least one EIGRP
autonomous system in the Setup tab. See EIGRP Page—Setup Tab, page K-226.
Navigation Path
Go to the EIGRP Routing Policy Page, page K-226, then click the Interfaces tab.
Related Topics
• Defining EIGRP Interface Properties, page 15-187
• EIGRP Page—Setup Tab, page K-226
• EIGRP Page—Redistribution Tab, page K-232
Field Reference
Table K-105 EIGRP Interfaces Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
AS Number The EIGRP autonomous system number for which interface properties are
defined.
Interfaces The interfaces related to the selected EIGRP autonomous system that have
specially defined values.
Split Horizon Indicates whether the split horizon feature is enabled or disabled for the
selected interface.
Hello Interval The defined interval between hello packets sent to neighboring routers.
Add button Opens the EIGRP Interface Dialog Box, page K-231. From here you can
create an EIGRP interface definition.
Edit button Opens the EIGRP Interface Dialog Box, page K-231. From here you can edit
the selected EIGRP interface definition.
Delete button Deletes the selected EIGRP interface definitions from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit icon on the toolbar.
