K-229
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
EIGRP Routing Policy Page
Edit Interfaces Dialog Box—EIGRP Passive Interfaces
When you configure an EIGRP routing policy on a Cisco IOS router, use the Edit
Interfaces dialog box to specify which interfaces will not send updates to their
routing neighbors.
Navigation Path
Go to the EIGRP Setup Dialog Box, page K-227, then click the Edit button in the
Passive Interfaces field.
Related Topics
• EIGRP Page—Setup Tab, page K-226
Field Reference
EIGRP Page—Interfaces Tab
Use the EIGRP Interfaces tab to create, edit, and delete interface properties for
selected EIGRP autonomous systems. This includes modifying the default hello
interval and disabling split horizon.
Table K-104 Edit Interfaces Dialog Box—EIGRP Passive Interfaces
Element Description
Interfaces The interfaces that do not send updates to their routing neighbors. You can
enter interfaces, interface roles, or both.
For more information, see Specifying Interfaces During Policy Definition,
page 9-135.
Select button Opens an Object Selectors, page F-593 for selecting interfaces and interface
roles. Using a selector eliminates the need to manually enter this
information.
If the interface role you want is not listed, click the Create button in the
selector to display the Interface Role Dialog Box, page F-464. From here
you can define an interface role object.
OK button Saves your changes and closes the dialog box. Your selections are displayed
in the Passive Interfaces field of the EIGRP Setup dialog box.
