K-227
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
EIGRP Routing Policy Page
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
EIGRP Setup Dialog Box
Use the EIGRP Setup dialog box to add or edit EIGRP routes.
Navigation Path
Go to the EIGRP Page—Setup Tab, page K-226, then click the Add or Edit button
beneath the table.
Table K-102 EIGRP Setup Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
AS Number The autonomous system number that identifies the autonomous system to
other routers.
Networks The names of the networks included in the route.
Passive Interfaces The interfaces that neither send nor receive routing updates from their
neighbors.
Auto-Summary Indicates whether auto summarization is activated on the selected route.
Add button Opens the EIGRP Setup Dialog Box, page K-227. From here you can create
an EIGRP route.
Edit button Opens the EIGRP Setup Dialog Box, page K-227. From here you can edit the
selected EIGRP route.
Delete button Deletes the selected EIGRP routes from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit icon on the toolbar.
