K-209
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Quality of Service Policy Page
Protocol One or more protocols included in this class map. Click Add to display a
selector. Select one or more items from the Available Protocols list, then
click >> to add them to the Selected Protocols list.
The only protocol available for the control plane is ARP; ARP and CDP are
not available for input classes configured on an interface.
When you finish, click OK to return to the QoS Class dialog box. Your
selections are displayed in the Protocol field.
Note To remove a protocol from the QoS class, select it from the Protocol
field, then click Delete.
Precedence One or more IP Precedence (IPP) values included in this class map. Click
Add to display a selector. Select one or more items from the Available
Precedences list, then click >> to add them to the Selected Precedences list.
Note For more information about IP precedence values, see Table 15-6 on
page 15-154.
When you finish, click OK to return to the QoS Class dialog box. Your
selections are displayed in the Precedence field.
Note To remove an IPP value from the QoS class, select it from the
Precedence field, then click Delete.
DSCP One or more Differentiated Services Code Point (DSCP) values included in
this class map. Click Add to display a selector. Select one or more items (up
to eight) from the Available DSCPs list, then click >> to add them to the
Selected DSCPs list.
When you finish, click OK to return to the QoS Class dialog box. Your
selections are displayed in the DSCP field.
Note To remove a DSCP value from the QoS class, select it from the DSCP
field, then click Delete.
ACL The ACLs that are used for defining which traffic requires QoS. Enter one or
more ACL objects, or click Select to display an Object Selectors,
page F-593. For more information, see Edit ACLs Dialog Box—QoS
Classes, page K-210.
Use the up and down arrows to order the ACLs in the list. We recommend
that you place frequently used ACLs at the top of the list to optimize the
matching process.
Table K-92 QoS Class Dialog Box—Matching Tab (Continued)
