Appendix K Router Platform User Interface Reference
Quality of Service Policy Page
K-208
User Guide for Cisco Security Manager 3.2
OL-16066-01
QoS Class Dialog Box—Matching Tab
Use the Matching tab of the QoS Class dialog box to define which traffic over the
selected interface is considered to be part of this class.
Note When you define the default class, the Matching tab is disabled.
Navigation Path
Go to the QoS Class Dialog Box, page K-205, then click the Matching tab.
Related Topics
• Defining QoS Class Matching Parameters, page 15-170
• Defining QoS on Interfaces, page 15-165
• Defining QoS on the Control Plane, page 15-168
• Quality of Service Policy Page, page K-199
• Understanding Access Control List Objects, page 9-30
Field Reference
Table K-92 QoS Class Dialog Box—Matching Tab
Element Description
Match Method The traffic matching option used for this class:
• Any—Assigns traffic matching any of the defined class map criteria to
this QoS class.
• All—Assigns only traffic matching all of the defined class map criteria
to this QoS class.
