K-207
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Quality of Service Policy Page
Field Reference
Note When you configure a QoS policy on the control plane, only the Matching tab and
Policing tab are available.
Table K-91 QoS Class Dialog Box
Element Description
Set as Default Class When selected, enables you to define the default class for all traffic that does
not match the other QoS classes on this interface.
When deselected, enables you to define a specific QoS class on this
interface.
Note When you define the default class, you do not configure any
matching parameters; by definition the class consists of all traffic
that does not match any of the other classes. Therefore, the Matching
tab is disabled.
Matching tab Defines the traffic that is included in this QoS class. See QoS Class Dialog
Box—Matching Tab, page K-208.
Marking tab Marks the traffic in this class so that downstream devices can properly
identify it. See QoS Class Dialog Box—Marking Tab, page K-211.
Queuing and
Congestion Avoidance
tab
Defines how to queue the output traffic in this class. See QoS Class Dialog
Box—Queuing and Congestion Avoidance Tab, page K-212.
Policing tab Limits the traffic flow for this class to a configured rate. See QoS Class
Dialog Box—Policing Tab, page K-214.
Shaping tab Controls the flow of output traffic for this class so that it conforms with the
requirements of downstream devices. See QoS Class Dialog Box—Shaping
Tab, page K-217.
