K-203
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Quality of Service Policy Page
QoS Policy Dialog Box
Use the QoS Policy dialog box to select an interface on which you want to define
QoS parameters. In addition, you can use this dialog box to configure a single set
of shaping parameters for all the traffic on the selected interface (known as
hierarchical shaping). Using hierarchical shaping eliminates the need to configure
shaping parameters for each QoS class defined on the interface.
Note This dialog box is not applicable when defining a QoS policy on the control plane.
For more information, see Defining QoS on the Control Plane, page 15-168.
After you create your QoS interface definitions, you can define one or more QoS
classes for each interface. For more information, see QoS Class Dialog Box,
page K-205.
Navigation Path
Go to the Quality of Service Policy Page, page K-199, then click the Add or Edit
button beneath the upper table to define a QoS interface definition.
Related Topics
• Defining QoS Policies, page 15-164
• Quality of Service on Cisco IOS Routers, page 15-151
• Basic Interface Settings on Cisco IOS Routers, page 15-20
• Understanding Interface Role Objects, page 9-132
Field Reference
Table K-90 QoS Policy Dialog Box
Element Description
Interface The interface on which QoS is defined. Enter the name of an interface or
interface role, or click Select to display an Object Selectors, page F-593.
If the interface role you want is not listed, click the Create button in the
selector to display the Interface Role Dialog Box, page F-464. From here
you can create an interface role object.
