Appendix K Router Platform User Interface Reference
Quality of Service Policy Page
Sustained Burst Applies only when you enable hierarchical shaping on this interface.
The normal burst size allowed on this interface, in milliseconds.
Excess Burst Applies only when you enable hierarchical shaping on this interface.
The excess burst size allowed on this interface, in milliseconds.
Add button Opens the QoS Policy Dialog Box, page K-203. From here you can select the
interface on which you want to define QoS parameters.
Edit button Opens the QoS Policy Dialog Box, page K-203. From here you can edit the
selected QoS interface.
Delete button Deletes the selected QoS interfaces from the table.
Interface QoS Classes Table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
No. The sequential number of the class. QoS is applied to packets on a
first-match basis, based on class order.
Default Class Indicates whether this class is the default for all packets on the interface that
do not match the criteria of the other defined classes.
Matching The matching criteria that determine whether packets are considered
members of this class. This includes the match method and any combination
of protocols, precedence and DSCP values, and ACL names.
Marking The IP Precedence (IPP) or Differentiated Services Code Point (DSCP)
setting for the traffic in this class.
Queuing and
Congestion Avoidance
The queuing settings that are defined for this class.
Policing Indicates whether policing is configured for this class.
Shaping Indicates whether Distributed Traffic Shaping (DTS) is configured for this
class.
Up Row Moves the selected class up one row.
Down Row Moves the selected class down one row.
Add button Opens the QoS Class Dialog Box, page K-205. From here you can create a
QoS class definition for the selected interface.
Table K-89 Quality of Service Page (Continued)
