Appendix K Router Platform User Interface Reference
Logging Setup Policy Page
K-192
User Guide for Cisco Security Manager 3.2
OL-16066-01
• Defining NAC Identity Parameters, page 15-143
• Understanding Access Control List Objects, page 9-30
Field Reference
Logging Setup Policy Page
Use the Logging Setup page to enable logging and define basic logging
parameters on the selected Cisco IOS router.
For more information, see Defining Logging Setup Parameters, page 15-146.
Table K-85 NAC Identity Action Dialog Box
Element Description
Name A descriptive name for the identity action. Use this name when you select an
action to assign to a NAC identity profile. See NAC Identity Profile Dialog
Box, page K-190.
Access Control Lists The ACL that defines how to handle traffic received from a device which is
assigned a profile that includes this action. Enter the name of an ACL object,
or click Add to display an Object Selectors, page F-593.
If the ACL you want is not listed, click the Create button in the selector to
display the dialog box for defining an ACL object (see Access Control Lists
Page, page F-31).
Note You cannot select the same ACL object that is being used for the
intercept ACL. See NAC Interface Configuration Dialog Box,
page K-187.
Redirect URL The address of the remediation server to which traffic from the device should
be redirected. Redirect URLs are usually of the form http://URL or
https://URL.
OK button Saves your changes locally on the client and closes the dialog box.
Note To save your changes to the Security Manager server so that they are
not lost when you log out or close your client, click Save on the
source page.
