K-19
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Router Interfaces Page
Note Unlike other router policies, the Interfaces policy cannot be shared among
multiple devices. The Advanced Settings policy, however, may be shared. See
Local Policies vs. Shared Policies, page 7-4.
Navigation Path
Go to the Router Interfaces Page, page K-17, then click the Add or Edit button
beneath the table.
Related Topics
• Basic Interface Settings on Cisco IOS Routers, page 15-20
• Deleting a Cisco IOS Router Interface, page 15-27
• Never Block Networks Dialog Box, page N-132
Field Reference
Table K-10 Create Router Interface Dialog Box
Element Description
Enabled When selected, the router interface is enabled.
When deselected, the router interface is in shutdown state. However, its
definition is not deleted.
Type Specifies whether you are defining an interface or subinterface.
Name Applies only to interfaces.
The name of the interface. Enter a name manually, or click Select to display
a dialog box for generating a name automatically. See Interface Auto Name
Generator Dialog Box, page K-24.
Note Logical interfaces require a number after the name:
—The valid range for dialer interfaces is 0-799.
—The valid range for loopback interfaces is 0-2147483647.
—The valid range for BVI interfaces is 1-255.
—The only valid value for null interfaces is 0.
Parent Applies only to subinterfaces.
The parent interface of the subinterface. Select the parent interface from the
displayed list.
