Appendix K Router Platform User Interface Reference
Network Admission Control Policy Page
K-186
User Guide for Cisco Security Manager 3.2
OL-16066-01
Network Admission Control Page—Interfaces Tab
Use the Network Admission Control Interfaces tab to select and configure the
router interfaces on which to perform NAC. This includes configuring the
Intercept ACL and selected EoU interface parameters. A NAC policy must include
at least one interface definition in order to function.
Navigation Path
Go to the Network Admission Control Policy Page, page K-183, then click the
Interfaces tab.
Related Topics
• Defining NAC Interface Parameters, page 15-140
• Network Admission Control Page—Setup Tab, page K-183
• Network Admission Control Page—Identities Tab, page K-189
Field Reference
Table K-81 Network Admission Control Interfaces Tab
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interfaces The name of the interface on which NAC is being performed.
Intercept ACL The name of the Intercept ACL, which determines the incoming traffic that
triggers the interface to make a posture validation check.
EoU Max Retries The maximum number of retries that this interface should perform when it
initializes an EoU session with a connecting device.
Revalidate Indicates whether the interface revalidates its EoU sessions to make sure
they are still active.
Add button Opens the NAC Interface Configuration Dialog Box, page K-187. From here
you can define a NAC interface.
Edit button Opens the NAC Interface Configuration Dialog Box, page K-187. From here
you can edit the selected NAC interface.
Delete button Deletes the selected NAC interfaces from the table.
