Appendix K Router Platform User Interface Reference
Router Interfaces Page
K-18
User Guide for Cisco Security Manager 3.2
OL-16066-01
Field Reference
Tip To choose which columns to display in the table, right-click a column header, then
select Show Columns. For more information about table display options, see
Table Columns and Column Heading Features, page 3-26.
Create Router Interface Dialog Box
Use the Create Router Interface dialog box to create and edit physical and virtual
interfaces on the selected Cisco IOS router.
Table K-9 Router Interfaces Page
Element Description
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Interface Type The interface type. Subinterfaces are displayed indented beneath their parent
interface.
Interface Name The name of the interface.
Enabled Indicates whether the interface is currently enabled (managed by Security
Manager) or disabled (shutdown state).
IP Address The IP address of interfaces defined with a static address.
IP Address Type The type of IP address assigned to the interface—static, DHCP, PPPoE, or
unnumbered. (IP address is defined by a selected interface role.)
Interface Role The interface roles that are assigned to the selected interface.
Add button Opens the Create Router Interface Dialog Box, page K-18. From here you
can create an interface on the selected router.
Edit button Opens the Create Router Interface Dialog Box, page K-18. From here you
can edit the selected interface.
Delete button Deletes the selected interfaces from the table.
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
