Appendix K Router Platform User Interface Reference
DHCP Policy Page
K-168
User Guide for Cisco Security Manager 3.2
OL-16066-01
Delete button Deletes the selected DHCP database agents.
Excluded IPs
Excluded IPs or IP
Ranges
The IP addresses and/or address ranges to exclude from DHCP. These
addresses are not assigned by the DHCP server to DHCP clients requesting
addresses.
Enter one or more network addresses or network/host objects, or click Select
to display an Object Selectors, page F-593.
If the network you want is not listed, click the Create button in the selector
to display the Network/Host Dialog Box, page F-477. From here, you can
define a network/host object.
For more information, see Specifying IP Addresses During Policy
Definition, page 9-153 and Supported IP Address Formats, page 9-145.
IP Pools Table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Name The name of the IP pool.
Network The IP address and subnet mask of the IP pool.
Default Router The IP addresses of the default routers used by DHCP clients.
DNS Server The IP addresses of the DNS servers used by DHCP clients.
NetBIOS (WINS)
Server
The IP addresses of the Windows Internet Naming Service (WINS) servers
used by Microsoft DHCP clients.
Domain Name The domain name for DHCP clients.
Import All Indicates whether the remote DHCP server imports certain DHCP options
from a centralized DHCP server.
Secured ARP Indicates whether secured ARP is enabled on this IP pool to help prevent IP
spoofing by unauthorized users.
Lease The duration of the lease for each IP address assigned by the DHCP server
from this IP pool.
Option 150 The IP address of the TFTP server required by IP phones for configuration,
as defined using DHCP option 150.
Table K-74 DHCP Policy Page (Continued)
