K-165
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Secure Device Provisioning Policy Page
Petitioner
Authentication
The CA server that authenticates the identity of the petitioner:
• Local CA Server—Select this option when the router itself is already
configured to act as the CA server. Enter the name of the local CA in the
field provided.
Note If you have not configured the router as the CA server, enter the
command Crypto pki server [name] using the CLI or FlexConfigs.
This command is mandatory when you deploy an SDP policy
configured with a local CA server.
• Remote CA Server—Select this option when using an external CA
server. Enter the name of a a PKI enrollment object, or click Select to
display an Object Selectors, page F-593.
If the server you want is not listed, click the Create button in either
selector to display the PKI Enrollment Dialog Box, page F-481. From
here you can define a PKI enrollment object.
Introduction Page The source of the introduction page to display to the introducer after
authorization is performed:
• Use default introduction page—Uses a default page provided with
Security Manager.
• Specify introduction page URL—Uses the introduction page specified
in the URL field. Supported protocols include: FTP, HTTP, HTTPS,
null, NVRAM, RCP, SCP, system, TFTP, Webflash, and XMODEM.
Table K-73 Secure Device Provisioning Page (Continued)
