Appendix K Router Platform User Interface Reference
SNMP Policy Page
K-154
User Guide for Cisco Security Manager 3.2
OL-16066-01
Community String Applies only when version 1 or version 2c is selected.
The password required to access the SNMP host. Enter the string again in the
Confirm field.
Note We recommend that you use one of the strings defined in the
Permissions table as the password to the SNMP host. You may,
however, enter a different password. String length ranges from 1 to
128 characters. Your entry does not appear in the Permissions table
and is read-only.
User Name Applies only when version 3 is selected.
The password required to access the SNMP host. Enter the string again in the
Confirm field.
Note We recommend that you use one of the strings defined in the
Permissions table as the password to the SNMP host. You may,
however, enter a different password. String length ranges from 1 to
128 characters. Your entry does not appear in the Permissions table
and is read-only.
SNMPv3 Security Applies only when version 3 is selected.
The level of security to apply to SNMP traffic:
• No MD5, No DES—No packet authentication.
• MD5 (auth)—MD5 authentication, but no encryption.
• DES (priv)—MD5 authentication and DES encryption.
UDP Port The port number for the SNMP host. The default is 162. Valid values range
from 0 to 65535.
OK button Saves your changes locally on the client and closes the dialog box.
Note To save your changes to the Security Manager server so that they are
not lost when you log out or close your client, click Save on the
source page.
Table K-67 Trap Receiver Dialog Box (Continued)
