Appendix K Router Platform User Interface Reference
SNMP Policy Page
K-150
User Guide for Cisco Security Manager 3.2
OL-16066-01
• (Policy view) Select Router Platform > Device Admin > Device Access >
SNMP from the Policy Type selector. Right-click SNMP to create a policy,
or select an existing policy from the Shared Policy selector.
Related Topics
• SNMP on Cisco IOS Routers, page 15-101
• Chapter K, “Router Platform User Interface Reference”
Field Reference
Ta b l e K - 6 5 S N M P Pa g e
Element Description
Permissions table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Community String The community string used for accessing the router’s MIB.
Type The community string type—read-only or read-write.
ACL The standard ACL that defines the IP addresses permitted to access the
router’s MIB.
Add button Opens the Permission Dialog Box, page K-151. From here you can enter the
community string and type required to generate traps.
Edit button Opens the Permission Dialog Box, page K-151. From here you can edit the
selected permissions profile.
Delete button Deletes the selected permissions profiles from the table.
Trap Receiver table
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Host IP Address The IP address of the SNMP host receiving the traps generated by the router.
SNMP Version The SNMP version being used by the router.
UDP Port The UDP port that is being used by the SNMP host.
Add button Opens the Trap Receiver Dialog Box, page K-153. From here you can define
the SNMP host that receives the traps generated by the router.
