Network Router User Manual
Table Of Contents
- Router Platform User Interface Reference
- NAT Policy Page
- Router Interfaces Page
- Advanced Interface Settings Page
- AIM-IPS Interface Settings Page
- Dialer Policy Page
- ADSL Policy Page
- SHDSL Policy Page
- PVC Policy Page
- PPP/MLP Policy Page
- AAA Policy Page
- Accounts and Credential s Policy Page
- Bridging Policy Page
- Clock Policy Page
- CPU Policy Page
- HTTP Policy Page
- Console Policy Page
- VTY Policy Page
- Secure Shell Policy Page
- SNMP Policy Page
- DNS Policy Page
- Hostname Policy Page
- Memory Policy Page
- Secure Device Provisioning Policy Page
- DHCP Policy Page
- NTP Policy Page
- 802.1x Policy Page
- Network Admission Control Policy Page
- Logging Setup Policy Page
- Syslog Servers Policy Page
- Quality of Service Policy Page
- BGP Routing Policy Page
- EIGRP Routing Policy Page
- OSPF Interface Policy Page
- OSPF Process Policy Page
- RIP Routing Policy Page
- Static Routing Policy Page
K-137
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
VTY Policy Page
VTY Line Dialog Box—Authorization Tab
Use the Authorization tab of the VTY Line dialog box to define the EXEC and
command authorization methods to perform on users who access the selected
VTY line or group of lines.
Note You must enable AAA services on the router to use this feature; otherwise,
deployment will fail. See Defining AAA Services, page 15-70.
Navigation Path
Go to the VTY Line Dialog Box, page K-131, then click the Authorization tab.
Related Topics
• Defining VTY Line AAA Settings, page 15-96
• VTY Line Dialog Box—Setup Tab, page K-132
• VTY Line Dialog Box—Authentication Tab, page K-136
• VTY Line Dialog Box—Accounting Tab, page K-139
Prioritized Method List Applies only when Custom Method List is selected as the authentication
method.
Defines a sequential list of methods to be queried when authenticating a user.
Enter the names of one or more AAA server group objects (up to four), or
click Select to display an Object Selectors, page F-593. Use the up and down
arrows in the object selector to define the order in which the selected server
groups should be used.
The device tries initially to authenticate users using the first method in the
list. If that method fails to respond, the device tries the next method, and so
on, until a response is received.
If the AAA server group you want is not listed, click the Create button in the
selector to display the AAA Server Group Dialog Box, page F-12. From here
you can define a AAA server group object.
Note If you select None as a method, it must appear as the last method in
the list.
Table K-59 VTY Line Dialog Box—Authentication Tab (Continued)
