K-135
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
VTY Policy Page
Output Protocols The protocols that you can use for outgoing connections on this line:
• All—All supported protocols are permitted. Supported protocols
include LAT, MOP, NASI, PAD, rlogin, SSH, Telnet, and V.120.
• None—No protocols are permitted. This makes the port unusable by
outgoing connections.
• Protocol—Enables one or more of the following protocols:
–
SSH—Secure Shell protocol.
–
Telnet—Standard TCP/IP terminal emulation protocol.
–
rlogin—UNIX rlogin protocol.
Note SSH and rlogin require that you configure AAA authentication. See
VTY Line Dialog Box—Authentication Tab, page K-136.
Note Not all IOS Software Versions support rlogin as an output protocol.
Inbound Access List The ACL that restricts incoming connections on this line. Enter the name of
an ACL object, or click Select to display an Object Selectors, page F-593.
If the extended ACL you want is not listed, click the Create button in the
selector to display the Add and Edit Extended Access List Pages, page F-34.
From here you can create an extended ACL object.
Permit VRF Interface
Connections
Applies only when an inbound ACL is defined on this line.
When selected, accepts incoming connections from interfaces that belong to
a VRF. When deselected, rejects incoming connections from interfaces that
belong to a VRF.
Outbound Access List The ACL that restricts outgoing connections on this line. Enter the name of
an ACL object, or click Select to display an Object Selectors, page F-593.
If the extended ACL you want is not listed, click the Create button in the
selector to display the Add and Edit Extended Access List Pages, page F-34.
From here you can create an extended ACL object.
Table K-58 VTY Line Dialog Box—Setup Tab (Continued)
