Network Router User Manual

Appendix K Router Platform User Interface Reference
VTY Policy Page
K-132
User Guide for Cisco Security Manager 3.2
OL-16066-01
VTY Line Dialog Box—Setup Tab
Use the Setup tab of the VTY Line dialog box to define the basic parameters of
the VTY line. This includes the password for accessing the line, the privilege level
assigned to users, the protocols that are permitted on the line, and the ACLs that
limit access.
Navigation Path
Go to the VTY Line Dialog Box, page K-131, then click the Setup tab.
Related Topics
• Defining VTY Line Setup Parameters, page 15-92
• VTY Line Dialog Box—Authentication Tab, page K-136
• VTY Line Dialog Box—Authorization Tab, page K-137
• VTY Line Dialog Box—Accounting Tab, page K-139
• Console Page—Setup Tab, page K-118
Field Reference
OK button Saves your changes locally on the client and closes the dialog box.
Note To save your changes to the Security Manager server so that they are
not lost when you log out or close your client, click Save on the
source page.
Table K-57 VTY Line Dialog Box (Continued)
Table K-58 VTY Line Dialog Box—Setup Tab
Element Description
Starting VTY Line
Number
The relative line number of the VTY line. If you are configuring a group of
VTY lines, enter the number of the first line in the group. Valid values range
from 0 to 15.
Note Although different routers support a different number of VTY lines
(from four to several thousand), Security Manager supports a
maximum of 16 lines per device. You cannot configure the same line
number more than once.
