Appendix K Router Platform User Interface Reference
Console Policy Page
K-124
User Guide for Cisco Security Manager 3.2
OL-16066-01
Prioritized Method List Applies only when Custom Method List is selected as the EXEC method.
Defines a sequential list of methods to be queried when authorizing a user.
Enter the names of one or more AAA server group objects (up to four), or
click Select to display an Object Selectors, page F-593. Use the up and down
arrows in the object selector to define the order in which the selected server
groups should be used.
The device tries initially to authorize users using the first method in the list.
If that method fails to respond, the device tries the next method, and so on,
until a response is received.
If the AAA server group you want is not listed, click the Create button in the
selector to display the AAA Server Group Dialog Box, page F-12. From here
you can define a AAA server group object.
Note If you select None as a method, it must appear as the last method in
the list.
Note RADIUS uses the same server for authentication and authorization.
Therefore, if you use define a RADIUS method list for
authentication, you must define the same method list for
authorization.
Command Authorization settings
Filter Enables you to filter the information displayed in the table. For more
information, see Filtering Tables, page 3-24.
Privilege Level The privilege level to which the command authorization definition applies.
Prioritized Method List The method list to use when authorizing users with this privilege level.
Add button Opens the Command Authorization Dialog Box—Line Access, page K-143.
From here you can configure a command authorization definition.
Edit button Opens the Command Authorization Dialog Box—Line Access, page K-143.
From here you can edit the command authorization definition.
Delete button Deletes the selected command authorization definitions from the table.
Authorization tab button
Save button Saves your changes to the Security Manager server but keeps them private.
Note To publish your changes, click the Submit button on the toolbar.
Table K-54 Console Page—Authorization Tab (Continued)
