Appendix K Router Platform User Interface Reference
Console Policy Page
K-120
User Guide for Cisco Security Manager 3.2
OL-16066-01
Output Protocols The protocols that you can use for outgoing connections on the console port:
• All—All supported protocols are permitted. Supported protocols
include LAT, MOP, NASI, PAD, rlogin, SSH, Telnet, and V.120.
• None—No protocols are permitted. This makes the port unusable by
outgoing connections.
• Protocol—Enables one or more of the following protocols:
–
SSH—Secure Shell protocol.
–
Telnet—Standard TCP/IP terminal emulation protocol.
–
rlogin—UNIX rlogin protocol.
Note SSH and rlogin require that you configure AAA authentication. See
Console Page—Authentication Tab, page K-121.
Note Not all IOS Software Versions support rlogin as an output protocol.
Inbound Access List The ACL that restricts incoming connections on the console port. Enter the
name of an ACL object, or click Select to display an Object Selectors,
page F-593. The object selector enables you to select either standard or
extended ACLs as well as to select or create a filter.
If the standard ACL you want is not listed, click the Create button in the
selector to display the Add and Edit Standard Access List Pages, page F-42.
From here you can create an ACL object.
Permit VRF Interface
Connections
Applies only when an inbound ACL is defined on the console port.
When selected, accepts incoming connections from interfaces that belong to
a VRF. When deselected, rejects incoming connections from interfaces that
belong to a VRF.
Outbound Access List The ACL that restricts outgoing connections on the console port. Enter the
name of an ACL object, or click Select to display an Object Selectors,
page F-593. The object selector enables you to select either standard or
extended ACLs as well as to select or create a filter.
If the standard ACL you want is not listed, click the Create button in the
selector to display the Add and Edit Standard Access List Pages, page F-42.
From here you can create an ACL object.
Table K-52 Console Page—Setup Tab (Continued)
