Network Router User Manual

K-119
User Guide for Cisco Security Manager 3.2
OL-16066-01
Appendix K Router Platform User Interface Reference
Console Policy Page
Privilege Level The privilege level assigned to users connected to the console port. Valid
values range from 0 to 15:
• 0—Grants access to these commands only: disable, enable, exit, help,
and logout.
• 1—Enables nonprivileged access to the router (normal EXEC-mode use
privileges).
• 15—Enables privileged access to the router (traditional enable
privileges).
Note Levels 2-14 are not normally used in a default configuration, but
custom configurations can be created by moving commands that are
normally at level 15 to a lower level and commands that are normally
at level 1 to a higher level. You can configure the privilege levels of
commands using the CLI or by defining a FlexConfig.
Note If you do not define a value, level 1 is assigned by default. This value
does not appear in the device configuration.
Disable all the EXEC
sessions to the router
via this line
When selected, disables EXEC sessions over this line. Select this option
when you want to allow only an outgoing connection on the console. This
option is useful for keeping the console port free from unsolicited incoming
data that can tie up the line.
When deselected, EXEC sessions are enabled on the console port. This is the
default.
Note Selecting this option blocks all access to the device via the console
port.
Exec Timeout The amount of time (in seconds) that the EXEC command interpreter waits
to detect user input on the console port. If no input is detected, the line is
disconnected. Valid values range from 0 to 2147483. The default is 600 (10
minutes). Setting the value to 0 disables the timeout.
Note Although the timeout is defined in seconds, it appears in the CLI in
the format [mm ss].
Table K-52 Console Page—Setup Tab (Continued)
