A-5
Cisco ASR 9000 Series Aggregation Services Router Overview and Reference Guide
OL-17501-09
Appendix A Technical Specifications
Table A-7 lists the AC electrical specifications for the Cisco ASR 9010 Router.
Shock Operating (halfsine): 21 in/sec (0.53 m/sec.)
Non-operating (trapezoidal pulse): 20 G
6
, 52 in/sec (1.32 m/sec)
Vibration Operating: 0.35 Grms
7
from 3 to 500 Hz
Non-operating: 1.0 Grms from 3 to 500 Hz
1. Operating temperature specifications for the router will differ from those listed in this table when 40-port Gigabit
Ethernet line cards using GLC-GE-100FX SFP transceiver modules are installed in the router. This is due to the lower
temperature specifications of the SFP module. Please contact a Cisco representative for more information.
2. Short term operating temperature specifications for the router will differ from those listed in this table when the
16-port 10-Gigabit Ethernet line card is installed in the router because of the lower temperature specifications of the
SFP+ modules that are used in this line card. When using this line card, the maximum operating temperature is 104°F
(40°C).
3. Short-term refers to a period of not more than 96 consecutive hours and a total of no more than 15 days in 1 year.
(This refers to a total of 360 hours in any given year, but no more than 15 occurrences during that 1-year period.).
4. The 24 port 10 Gigabit Ethernet linecard requires high temperature optics to run in the extended temperature range.
5. Operating altitude specifications for the router will differ from those listed in this table when the 16-port 10-Gigabit
Ethernet line card is installed in the router. When using the SFP-10G-SR module, the maximum altitude is 5905 ft.
(1800 m). When using the SFP-10G-LR or SFP-10G-ER modules, the maximum altitude is sea level.
6. G is a value of acceleration, where 1 G equals 32.17 ft./sec
2
(9.81 m/sec
2
).
7. Grms is the root mean square value of acceleration.
Table A-6 Cisco ASR 9000 Series Environmental Specifications (continued)
Description Value
Table A-7 Cisco ASR 9010 Router AC Electrical Specifications
Description Value
Power modules per system Version 1 power system:
Up to six AC power modules per system, three per tray
Version 2 power system:
Up to eight AC power modules per system, four per tray
Total AC input power per
power module
3400 VA (volt-amps)
Rated input voltage per
power module
200–240 VAC nominal (range: 180 to 264 VAC)
220–240 VAC (UK)
Rated input line frequency
1
50/60 Hz nominal (range: 47 to 63 Hz)
50/60 Hz (UK)
Input current draw
1
15 A maximum at 200 VAC
13 A maximum at 220 to 240 VRMS (UK)
Source AC service
requirement
1
1. For each AC power supply module. Some power/chassis configurations may operate at lower current ratings than those
specified in this table. Contact your Cisco technical representative for more information.
20 A North America; 16 A international; 13 A UK
Redundancy At least four AC power modules (two per power tray) are required for
2N redundancy for a fully configured system (version 1 and version 2).
