C H A P T E R 1 Product Overview This chapter consists of the following primary sections: • Cisco 7600 Router Manager Software Overview • Supported Hardware • Supported Software The Cisco 7600 Router Manager software manages and monitors Cisco 7600 series internet routers using Cisco Element Management Framework (Cisco EMF), version 3.2. The Cisco 7600 Router Manager provides standard element management functionality, such as fault, configuration, accounting, performance, and security (FCAPS).
Chapter 1 Product Overview Cisco 7600 Router Manager Software Overview Cisco 7600 Router Manager Software Overview The Cisco 7600 Router Manager software adds custom windows and modeling behavior to the standard Cisco EMF system to provide management of the Cisco 7600 series internet routers.
Chapter 1 Product Overview Cisco 7600 Router Manager Software Overview • Many operations can be performed to several Cisco 7600 series internet routers, simplifying the management of a large deployment of multiple switches • Event browser or performance manager provide historical information analysis • Configuration of Ethernet, PoS, ATM, and Sonet modules • Configuration management, including backup and restore operations • Software-download management Cisco 7600 Router Manager User Guide OL-65
Chapter 1 Product Overview Supported Hardware Supported Hardware The following table lists hardware supported by the Cisco 7600 Router Manager, release 3.2.
Chapter 1 Product Overview Supported Hardware Table 1-1 Supported Hardware (continued) Part Number Description WS-X6248A-TEL 48-port 10/100TX, RJ-21, 128K per port packet buffers WS-X6348-RJ-45 48-port 10/100TX, RJ-45, 128K per port packet buffers WS-X6348-RJ45V 48-port 10/100TX, RJ-45, 128K per port packet buffers with WS-X6348-RJ21 48-port 10/100, RJ-21, upgradable to voice WS-X6348-RJ21V 48-port 10/100, RJ-21, inline power WS-X6524-100FX-MM Fabric-enabled 100FX Fast Ethernet Module, mult
Chapter 1 Product Overview Supported Hardware Table 1-1 Supported Hardware (continued) Part Number Description OSM-4GE-WAN-GBIC 4-port Gigabit Ethernet Optical Services Module, GBIC OSM-4OC12-POS-MM 4-port OC-12/STM-4 SONET/SDH OSM, MM, with 4 ports Ethernet OSM-4OC12-POS-SI 4-port OC-12/STM-4 SONET/SDH OSM, SM-IR, with 4 po Gigabit Ethernet OSM-4OC12-POS-SI+ Enhanced 4-port OC-12/STM-4 SONET/SDH OSM, SM-IR OSM-4OC12-POS-SL 4-port OC-12/STM-4 SONET/SDH OSM, SM-LR, with 4 p Gigabit Ethernet
Chapter 1 Product Overview Supported Hardware Table 1-1 Supported Hardware (continued) Part Number Description OSM-2CHOC48/T3-SS 2-port CHOC-48/CHSTM-16 OSM, to T3/E3, SM-SR, with OSM-1OC48-POS-SL 1-port OC-48/STM-16 SONET/SDH OSM, SM-LR, with 4 Gigabit Ethernet OSM-16OC3-POS-MM 16-port OC-3/STM-1 SONET/SDH OSM, MM, with 4 ports Ethernet OSM-16OC3-POS-SI 16-port OC-3/STM-1 SONET/SDH OSM, SM-IR, with 4 po Gigabit Ethernet OSM-16OC3-POS-SL 16-port OC-3/STM-1 SONET/SDH OSM, SM-LR, with 4 p Gigab
Chapter 1 Product Overview Supported Hardware Table 1-1 Supported Hardware (continued) Part Number Description OSM-4CHOC12/T3-SI 4-port channelized OC-12 OSM, SI, with 4 ports of Gigabit OSM-8CHOC12/T3-MM 8-port channelized OC-12 OSM, MM, with 4 ports of Gigab OSM-8CHOC12/T3-SI 8-port channelized OC-12 OSM, SI, with 4 ports of Gigabit PA-2E3 2 Port E3 Serial Port Adapter with E3 DSUs PA-2H 2-Port HSSI Port Adapter PA-2T3 2 Port T3 Serial Port Adapter PA-2T3+ 2 Port T3 Serial Port Adapter
Chapter 1 Product Overview Supported Hardware Table 1-1 Supported Hardware (continued) Part Number Description PA-T3+ 1 Port T3 Serial Port Adapter Enhanced PA-A3-8E1IMA 8-port ATM Inverse Mux E1 (120 Ohm) Port Adapter PA-MC-4T1 4 port multichannel T1 port adapter with integrated CSU/DS GE-WAN2 2-port Gigabit Ethernet Cisco 7600 Router Manager User Guide OL-6563-01 1-9
Chapter 1 Product Overview Supported Software Supported Software The Cisco 7600 Router Manager 3.2 supports the following IOS software. Note • Cisco 7603 and 7609 router—12.1(12c)E5 , 12.1(13)E4, 12.2(17a)SX10, and 12.1(19)E1 • Cisco 7609 router—12.1(12c)E4, 12.2(17b)SXA, and 12.1(19)E1 The above versions of IOS have been extensively tested with the Cisco 7600 Router Manager software.
