12-3
Cisco ONS 15454 SDH Reference Manual, R5.0
April 2008
Chapter 12 CTC Network Connectivity
12.2.2 Scenario 2: CTC and ONS 15454 SDH Nodes Connected to a Router
Figure 12-1 Scenario 1: CTC and ONS 15454 SDH Nodes on the Same Subnet
12.2.2 Scenario 2: CTC and ONS 15454 SDH Nodes Connected to a Router
In Scenario 2 the CTC computer resides on a subnet (192.168.1.0) and attaches to LAN A (Figure 12-2).
The ONS 15454 SDH nodes reside on a different subnet (192.168.2.0) and attach to LAN B. A router
connects LAN A to LAN B. The IP address of router interface A is set to LAN A (192.168.1.1), and the
IP address of router interface B is set to LAN B (192.168.2.1).
On the CTC computer, the default gateway is set to router interface A. If the LAN uses Dynamic Host
Configuration Protocol (DHCP), the default gateway and IP address are assigned automatically. In the
example shown in Figure 12-2, a DHCP server is not available.
CTC Workstation
IP Address 192.168.1.100
Subnet Mask 255.255.255.0
Default Gateway = N/A
Host Routes = N/A
ONS 15454 SDH #1
IP Address 192.168.1.10
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
ONS 15454 SDH #2
IP Address 192.168.1.20
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
ONS 15454 SDH #3
IP Address 192.168.1.30
Subnet Mask 255.255.255.0
Default Router = N/A
Static Routes = N/A
LAN A
SDH RING
71295
