C-2
Cisco Aironet 1300 Series Wireless Outdoor Access Point/Bridge Hardware Installation Guide
OL-5048-06
Appendix C Access Point Specifications
Operational vibration SAE J1455 Power injector—SAE J1455
Non-operational
vibration
SAE J1455 Power injector—SAE J1455
Environmental testing
compliance
The enclosure has been successfully tested and is in
compliance with a NEMA 4 enclosure rating.
—
Weight 2.5 lbs (1.13 kg) Power injector—0.8 lbs (0.36 kg)
Power module—1.0 lbs (0.5 kg)
Input voltage 48 VDC (nominal)
53 VDC (maximum)
Power injector (nominal):
48 VDC (LR2 power injector)
12 to 40 VDC (LR2T power injector)
Power module:
100 to 240 VAC
Power consumption 13W (typical) —
Radio output power For autonomous access points/bridges:
100, 50, 30, 20, 10, 5, or 1 mW
(at 1, 2, 5.5, and 11 Mbps)
30, 20, 10, 5, or 1 mW
(at 6, 9, 12, 18, 24, 48, and 54 Mbps)
For lightweight access points:
100, 50, 25, 12, 6, 3, 2, or 1 mW
(at 1, 2, 5.5, and 11 Mbps)
30, 15, 8, 4, 2, or 1 mW
(at 6, 9, 12, 18, 24, 48, and 54 Mbps)
(Depending on the regulatory domain in which the
access point/bridge is installed)
Power injector:
18W (maximum at 48 VDC) supplied to
the access point/bridge through dual-coax
cables
Power module:
18W (maximum at 48 VDC)
Frequency 2.400 to 2.497 GHz
(Depending on the regulatory domain in which the
access point/bridge is installed)
—
Modulation IEEE 802.11b-compliant radio:
Direct Sequence Spread Spectrum (DSSS)
Complementary Code Keying (CCK)
IEEE 802.11g-compliant radio:
Orthogonal Frequency Division Multiplex
(OFDM)
—
Subcarrier modulation CCK (5.5 Mbps and 11 Mbps)
BPSK (1 Mbps, 6 Mbps and 9 Mbps)
QPSK (2 Mbps, 12 Mbps and 18 Mbps)
16-QAM (24 Mbps and 36 Mbps)
64-QAM (48 Mbps and 54 Mbps)
—
Table C-1 Access Point, Power Injector, and Power Module Specifications (continued)
Category Access Point Power Injector and Power Module
