3-7
Cisco Aironet 1300 Series Wireless Outdoor Access Point/Bridge Hardware Installation Guide
OL-5048-06
Chapter 3 Mounting Overview
LEDs
When using LEDs to maximize the signal, adjust the antenna until as many LEDs as possible are turned
on and the rest are blinking as fast as possible.
Table 3-3 Bridge LED Installation Mode RSSI Display
RSSI Level (dBm) Ethernet LED Status LED Radio LED
> –44 On On On
–47 to –44 Fast blink
1
1. Slow blinking rate of 1 blink/sec.
On On
–50 to –47 Medium blink
2
2. Medium blinking rate of 2 blinks/sec.
On On
–53 to –50 Slow blink
3
3. Fast blinking rate of 4 blinks/sec.
On On
–54 to –53 Off On On
–57 to –54 Off Fast blink
1
On
–60 to –57 Off Medium blink
2
On
–63 to –60 Off Slow blink
3
On
–66 to –63 Off Off On
–69 to –66 Off Off Fast blink
1
–72 to –69 Off Off Medium blink
2
–75 to –72 Off Off Slow blink
3
< –75 Off Off Off
