2-8
Cisco Aironet 1300 Series Wireless Outdoor Access Point/Bridge Hardware Installation Guide
OL-5048-06
Chapter 2 Installation Overview
Before Beginning the Installation
Figure 2-2 Access Point/Bridge Layout
Figure 2-3 Power Injector Indicators and Connectors
1 Grounding studs 4 LEDs
2 Antenna connectors 5 Dual-coax Ethernet ports (F-Type connectors)
3 Mounting lugs
117060
1
2
3
4
5
1 Dual-coax Ethernet ports (F-Type connectors) 4 Ethernet LAN port (RJ-45 connector)
2 Power LED 5 Console serial port (RJ-45 connector)
3 Power jack
117189
CISCO AIRONET
POWER INJECTOR
54
11
3
2
