Table Of Contents
- Cisco Aironet 1300 Series Wireless Outdoor Access Point/Bridge Hardware Installation Guide
- Contents
- Preface
- Overview
- Installation Overview
- Mounting Overview
- Troubleshooting Autonomous Access Points and Bridges
- Checking the LEDs on an Autonomous Access Point/Bridge
- Power Injector
- Checking Power
- Checking Basic Configuration Settings
- Antenna Alignment
- Running the Carrier Busy Test
- Running the Ping or Link Test
- Resetting the Autonomous Access Point/Bridge to the Default Configuration
- Reloading the Access Point/Bridge Image
- Obtaining the Autonomous Access Point/Bridge Image File
- Connecting to the Console Serial Port
- Obtaining the TFTP Server Software
- Troubleshooting Lightweight Access Points
- Translated Safety Warnings
- Declarations of Conformity and Regulatory Information
- Manufacturers Federal Communication Commission Declaration of Conformity Statement
- VCCI Statement for Japan
- Industry Canada
- European Community, Switzerland, Norway, Iceland, and Liechtenstein
- Declaration of Conformity for RF Exposure
- Guidelines for Operating Cisco Aironet Access Points and Bridges in Japan
- Administrative Rules for Cisco Aironet Access Points and Bridges in Taiwan
- Operation of Cisco Aironet Access Points in Brazil
- Declaration of Conformity Statements
- Access Point Specifications
- Channels and Maximum Power Levels
- Console Serial Cable Pinouts
- Priming Lightweight Access Points Prior to Deployment
- Configuring DHCP Option 43 for Lightweight Access Points
- Load-Dump Protection for Transportation Vehicles
- Glossary
- Index
CHAPTER
1-1
Cisco Aironet 1300 Series Wireless Outdoor Access Point/Bridge Hardware Installation Guide
OL-5048-06
1
Overview
The Cisco Aironet 1300 Series Outdoor Access Point/Bridge is available in autonomous and lightweight
products. The autonomous product can support standalone network configurations with all configuration
settings maintained within the unit. The autonomous product can be configured for multiple operating
roles such as, access point, bridge, and workgroup bridge. The lightweight product operates in
conjunction with a Cisco wireless LAN controller with all configuration information maintained within
the controller. The lightweight product can be only configured as an access point.
Product Terminology
The following terms refer to the autonomous and lightweight products:
• The term access point/bridge describes both autonomous and lightweight products.
• The term autonomous access point/bridge describes only the autonomous product.
• The term lightweight access point describs only the lightweight product.
• The term access point describes the product when configured to operate as an access point.
• The term bridge describes the product when configured to operate as a bridge.
Autonomous Access Point/Bridge
The autonomous access point/bridge (model: AIR-BR1310G) supports a management system based on
Cisco IOS software. The access point/bridge is a Wi-Fi certified, wireless LAN transceiver. The
autonomous access point/bridge uses a single mini-PCI radio (IEEE 802.11b-compliant or IEEE
802.11g-compliant) that can be upgraded to future radio technologies.
The autonomous access point/bridge serves as the connection point between wireless and wired
networks or as the center point of a stand-alone wireless network. In large installations, wireless users
within radio range of an access point can roam throughout a facility while maintaining uninterrupted
access to the network.
You can configure and monitor the autonomous access point/bridge using the command-line interface
(CLI), the browser-based management system, or Simple Network Management Protocol (SNMP).
