Chapter 4 Advanced Correlation Scenarios
Generic Routing Encapsulation (GRE) Tunnel Down/Up
GRE Tunnel Down Correlation Example 2
This example provides a real world scenario, whereby multiple GRE tunnels cross through a physical
link. When this link is shut down by an administrator, many alarms are generated. All the alarms are
correlated to the root cause ticket "Link down due to admin down”, as illustrated in Figure 4-15.
Figure 4-15 GRE Tunnel Down Example 2 (Multiple GRE Tunnels)
