- Cisco7010 and Cisco 7505 ChassisReplacementInstructions
- Product Overview
- Prerequisites
- Replacing the Chassis
- Replacing a Rack-Mounted Chassis
- Removing the Existing Chassis from the Rack
- Step 1 Turn off the system power and disconnect the power cord and all interface cables from the ...
- Step 2 Have a second person support the chassis while you perform this step. From the front of th...
- Step 3 Pull the chassis out of the rack and place it on the floor or a table.
- Step 4 Use a number2 Phillips screwdriver to loosen and remove the two M4 x 10-mm, Phillips flat...
- Step 5 Pull the ears off the chassis, and place the ears and all fasteners aside.
- Installing the New Chassis in the Rack
- Step 1 Position the chassis so that the end that will be in the front of the rack is closest to y...
- Step 2 Attach the right chassis ear to the chassis first. Hold the ear in the orientation shown i...
- Step 3 Insert the two studs through the holes on the side of the chassis. The ear should be flush...
- Step 4 Insert two M4 x 10-mm, Phillips flathead screws through the ears and into the chassis side...
- Step 5 Repeat Steps2through4 for the left ear. The strip of mounting holes on the front of eac...
- Step 6 Lift the chassis and move it to the rack. Avoid sudden twists or moves to prevent injury.
- Step 7 Insert the rear of the chassis into the rack, pushing it back until the ears meet the fron...
- Step 8 From the front of the rack, insert all eight 10-32x3/8-inch, slotted screws (four on eac...
- Step 9 When all screws are inserted, use a 1/4-inch, flat-blade screwdriver to tighten each one.
- Removing the Existing Chassis from the Rack
- Installing the Cable Management Brackets
- Figure7 Cable Management Brackets—Cisco 7010 Shown
- Step 1 If you have new brackets to install on the new chassis, proceed to Step4. If you are remo...
- Step 2 At the interface processor end of the existing chassis, push the cables out of the cutouts...
- Step 3 Use a number1 Phillips screwdriver to remove the sixpanhead screws (threeper bracket) t...
- Step 4 At the interface processor end of the new chassis, place a bracket on one of the inner sid...
- Step 5 Insert and finger-tighten three M3 Phillips screws from the inner side of the chassis, thr...
- Step 6 When all three screws are inserted, use the number1 Phillips screwdriver to tighten the s...
- Step 7 Repeat Steps 4 through 6 for the second bracket.
- Step 8 When connecting the network interface cables or installing processor modules with the inte...
- Moving Processor Modules
- Figure8 Ejector Levers and Captive Installation Screws
- Step 1 Before moving any processor modules, ensure that you have met the following prerequisites ...
- Step 2 Note the slot location of the interface processor you will move. Before removing the inter...
- Step 3 If necessary, disconnect any interface cables that are connected to the processor module.
- Step 4 Use a screwdriver to loosen both of the captive installation screws. (See Figure8a.)
- Step 5 Place your thumbs on the end of each ejector and simultaneously pull them both outward, aw...
- Step 6 Grasp the carrier handle with one hand and pull the processor module straight out of the s...
- Step 7 Place the processor module in the same slot position in the new chassis and align the notc...
- Step 8 While keeping the carrier at a 90-degree orientation to the backplane, carefully slide the...
- Step 9 Using the thumb and forefinger of each hand to pinch each ejector, simultaneously push bot...
- Step 10 Use a screwdriver to tighten the two captive screws to prevent the processor module from ...
- Step 11 Repeat Steps2through10 for the remaining interface processors.
- Step 12 Repeat Steps3through10 for the SP (or SSP) and RP in the Cisco 7010, and the RSP1 in t...
- Checking the Installation
- Step 1 Ensure that the system power switch is in the off position, then reconnect the power cable...
- Step 2 Connect all interface cables to the appropriate interface processor ports. Ensure that all...
- Step 3 Ensure that you have either a console terminal connected to the system console port or a p...
- Step 4 Turn on the system power. The DC OK LED should go on and stay on. If if does, proceed to t...
- Step 5 While the system initializes, the yellow boot error LED on the RP should go on for about t...
- Step 6 When the system boot is complete, the RP or RSP1 begins to initialize the interface proces...
- Step 7 If the enabled LED on a single interface processor remains off, suspect that the interface...
- Step 8 If an enabled LED still fails to go on after performing these steps, suspect that the spec...
- Step 9 Verify that the console terminal displays a script and system banner similar to the follow...
- Step 10 After the system initializes, use the various show commands to display the status of the ...
- show Command Descriptions and Examples
- Replacing a Rack-Mounted Chassis
- Cisco Information Online

14 Cisco 7010 and Cisco 7505 Chassis Replacement Instructions
Replacing the Chassis
Moving Processor Modules
At the interface processor end of the chassis, slots contain the processor modules. (See Figure 1 or
Figure 2.) In the Cisco 7010, the RP occupies the top slot (the RP slot or slot 4) and the SP (or SSP)
occupies the second slot from the top (the SP slot or slot 3), directly below the RP slot. The
remaining three slots, which are numbered 0 through 2 beginning at the bottom slot, support any
combination of interface processors.
In the Cisco 7505, the RSP1 occupies the top slot (slot 4). The remaining four slots, numbered 0
through 3 beginning at the bottom, support any combination of interface processors.
The processor modules are all keyed with guides on the backplane to prevent them from being fully
inserted in the wrong slot. Empty interface processor slots contain an interface processor filler (an
empty carrier) to help keep dust out of the chassis, provide EMI shielding, and maintain proper air
flow through the chassis interior.
Processor modules slide into the processor slots and connect directly to the backplane. The
spring-loaded ejector levers (see Figure 8) help to ensure that the bus connector on the back of the
processor module is fully seated in the backplane or fully dislodged from it. Captive installation
screws at both ends of each processor module faceplate prevent the processor from pulling away
from the backplane and support the EMI integrity of the system. Failure to use the ejector levers and
captive installation screws could result in a partial backplane connection, which can hang the system.
To retain your existing configuration, move interface processors to the same slot positions in the new
chassis. The lithium battery backup on the RP and RSP1 retains the system configuration and
MAC-layer addresses in nonvolatile random-access memory (NVRAM). Therefore, if you install
interface processors in the same slot positions in the new chassis that they occupied in the old
chassis, the system and the individual interfaces should come up in their previous configuration. If
you install interface processors in different slots in the new chassis, the system will recognize the
interfaces, but will leave them in a shutdown state until you reconfigure and enable them.
Although interface processors support OIR, you must wait at least 15 seconds after inserting an
interface processor before inserting the next one. To help avoid errors with the installation, leave the
power off until all components are moved into the new chassis and you have verified that all are
installed properly.
In the chassis, move the interface processors first, one at a time, then, in the Cisco 7010, move the
SP (or SSP) and finally the RP; in the Cisco 7505, move the RSP1 last. Before you remove an
interface processor from the existing chassis, remove the interface processor filler from the
corresponding slot in the new chassis. Then immediately install the interface processor in the new
chassis and secure it in the slot before removing the next interface processor filler or module. If you
leave the interface cables attached to the interface processors, route the cables through the cable
management brackets immediately after you secure the interface processor in the slot to help keep
the other slots clear during the installation.
If there is sufficient slack in the interface cables, and if you can easily move the processor modules
between the chassis without straining the cables, leave the interface cables connected. If you must
disconnect the cables, label each cable with its slot and port number before you disconnect it. Do not
reconnect the interface cables until you have installed all of the components in the new chassis (it is
easier to install interface processors when the slots are not impeded by cables that drop from other
slots). Use the optional cable management brackets to keep the interface cables untangled and away
from other interface processor slots and ports.
Caution You must turn off the system power before removing or installing the RP, SP (or SSP), or
RSP1, all of which are required system components. Removing one while the system is operating
will cause the system to shut down or crash and might damage or destroy memory files.
