Replacing the Chassis
Step 6 When the system boot is complete, the RP or RSP1 begins to initialize the interface
processors. During this initialization, the LEDs on each interface processor behave
differently (most flash on and off). The enabled LED on each interface processor goes on
when initialization has been completed.
• If the enabled LED on the SP (or SSP) and all interface processors go on, the system
has booted successfully and is now functional.
• If the RP or RSP1 LEDs previously indicated a successful system boot, but none of the
enabled LEDs on the SP (or SSP) or the interface processors go on, suspect that one of
them has shifted out of its backplane connector and hung the bus. Turn off the power,
then use the ejector levers to release the SP (or SSP) and each interface processor and
reseat them in their slots. (Refer to the section “Moving Processor Modules” on page 14
for removal and insertion steps.) Tighten all captive installation screws, then return to
Step 1.
Step 7 If the enabled LED on a single interface processor remains off, suspect that the interface
processor has shifted out of its slot. Use the ejector levers to release the interface processor
and reseat it in the backplane. (Refer to the section “Moving Processor Modules” on
page 14, for removal and insertion steps.) Tighten both captive installation screws, then
return to Step 1.
Step 8 If an enabled LED still fails to go on after performing these steps, suspect that the specific
SP (or SSP) or interface processor has failed. Contact a service representative.
Step 9 Verify that the console terminal displays a script and system banner similar to the
following:
GS Software (GS7), Version 10.3(3), SOFTWARE
Copyright (c) 1986-1995 by cisco Systems, Inc.
Compiled Wed 10-May-95 14:46 by mpo
System Bootstrap, Version 4.6(1) [fc2], SOFTWARE
Step 10 After the system initializes, use the various show commands to display the status of the
system and individual interfaces, and ensure that they are operating according to their
previous configuration. (For descriptions and examples of these commands, refer to the
following section, “show Command Descriptions and Examples.”)
When the system starts up and operates successfully, the replacement procedure is complete and you
can resume normal operation.
If the system still fails to start up or operate properly, or if you isolate the cause of the problem to a
failed component, contact a service representative for further assistance.
Note After you verify a successful installation, gather the old chassis and any remaining spares and
parts. If the old chassis is still mounted in a rack, follow the steps in the section “Removing the
Existing Chassis from the Rack” on page 10 to remove it. Place spare interface processors or
interface processor fillers in the chassis slots, and move the chassis to the appropriate location for
storage or shipment.
