C H A P T E R 6 Command Reference This chapter lists new and revised commands specific to the MWAM configuration. The commands are categorized according to the console from which they are executed.
Chapter 6 Command Reference Processor Control Commands Processor Control Commands The Processor Control (PC) commands are available when you session into MWAM processor 1 from the Supervisor console. The PC commands provide various functions for MWAM processors. To access the PC commands, use the session slot command to establish a connection to processor 1. Then log into the PC as root user with the password cisco.
Chapter 6 Command Reference Command Details Command Details mwam module allowed-vlan To configure the Ethernet connectivity from the backplane (i.e., switch fabric) to the individual processors on the MWAM, use the mwam module allowed-vlan command in global configuration mode. To remove this configuration, use the no form of the command.
Chapter 6 Command Reference Command Details mwam module vlan-based To assign MWAM traffic to a VLAN QoS policy, use the mwam module vlan-based command in global configuration mode. To remove this configuration, use the no form of the command. mwam module slot_number port port_number vlan-based no mwam module slot_number port port_number vlan-based Syntax Description slot_number Specifies the slot that the module is plugged into.
Chapter 6 Command Reference Command Details session slot To establish a command session to a processor on an MWAM, use the session slot command in privileged EXEC mode. session slot slot_number processor processor_number Syntax Description slot_number Specifies the slot that the MWAM is plugged into. processor processor_number Specifies the MWAM processor (1-6) to connect to.
Chapter 6 Command Reference Command Details Tue Oct 14 11:04:43 EDT 2003 Copyright (c) 2002-2003 by cisco Systems, Inc. All rights reserved. Kernel 2.4.10.komodo on an i686 login: root Password: SVCMWAM Image version 2.1(0.1b) Tue Oct 14 11:04:43 EDT 2003 Copyright (c) 2002-2003 by cisco Systems, Inc. All rights reserved. SVCMWAM Image version 2.1(0.1b) Tue Oct 14 11:04:43 EDT 2003 Copyright (c) 2002-2003 by cisco Systems, Inc. All rights reserved.
Chapter 6 Command Reference Command Details show mwam module To display connectivity information about the individual processors on the MWAM, use the show mwam module command in privileged EXEC mode. show mwam module slot_number port port_number {state | traffic} Syntax Description slot_number Displays the slot that the module is plugged into. port port_number Displays the actual port number (1-3) used to connect to a processor complex within an MWAM (Figure 1-1).
Chapter 6 Command Reference Command Details Last clearing of "show interface" counters never Input queue: 0/2000/0/0 (size/max/drops/flushes); Total output drops: 67 Queueing strategy: fifo Output queue :0/40 (size/max) 5 minute input rate 0 bits/sec, 0 packets/sec 5 minute output rate 1000 bits/sec, 3 packets/sec 0 packets input, 0 bytes, 0 no buffer Received 0 broadcasts, 0 runts, 0 giants, 0 throttles 0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored 0 input packets with dribble condition detected
Chapter 6 Command Reference Command Details Administrative Trunking Encapsulation: dot1q Operational Trunking Encapsulation: dot1q Negotiation of Trunking: Off Access Mode VLAN: 1 (default) Trunking Native Mode VLAN: 1 (default) Trunking VLANs Enabled: 1-999 Pruning VLANs Enabled: 2-1001 Vlans allowed on trunk:1-999 Vlans allowed and active in management domain:1,3,11-12,17,60 Vlans in spanning tree forwarding state and not pruned: 1,3,11-12,17,60 Allowed-vlan : 1-999 Sup-7606#sho mwam mod 7 port 3 traffi
Chapter 6 Command Reference Command Details mwam bootflash access Note The MWAM bootflash access must be enabled if you want to operate in Supervisor mode. To enable file transfer requests between the Supervisor bootflash and the individual processors on the MWAM, use the mwam bootflash access command in configuration mode. To remove this configuration, use the no form of the command.
Chapter 6 Command Reference Command Details logging listen mwam To configure MWAM logging input to the Supervisor from an MWAM in the chassis, use the logging listen mwam command in global configuration mode. To remove this configuration, use the no form of the command. logging listen mwam udp_port no logging listen mwam udp_port Syntax Description udp_port Specifies the UDP port on the Supervisor module for listening to logs from MWAM(s) in the chassis.
Chapter 6 Command Reference Command Details MWAM Processor: Base UDP Port: 1 2 3 4 5 6 <40-100>00 <40-100>00 <40-100>00 <40-100>00 <40-100>00 Additional UDP Port: <40-100>02 <40-100>03 <40-100>04 <40-100>05 <40-100>06 Additional UDP Port: <40-100>12 <40-100>13 <40-100>14 <40-100>15 <40-100>16 1. Must be in the range 4000-10000 and be a multiple of 100. The port numbering pattern is important if you are configuring other UDP ports on either the Supervisor or the MWAM processor.
Chapter 6 Command Reference Command Details execute-on To initiate a remote command request on an MWAM processor from the Supervisor console, use the execute-on command in privileged EXEC mode. execute-on {slot_number | all} {processor_number | all} command [subcommand] Syntax Description slot_number Specifies the slot that the module is plugged into. all Specifies all the MWAMs in the chassis.1 processor_number Specifies the processor number within the MWAM.
Chapter 6 Command Reference Command Details To terminate a remote command that is in progress, the user can activate the escape sequence defined on the Supervisor console. For example, if a user initiates a log show command on a remote MWAM processor and the command execution is longer than expected, the user can terminate the command from the Supervisor console by entering Ctrl-^. To determine the escape sequence for your console/vty connection, use the show line line_number command.
Chapter 6 Command Reference Command Details mwam module cpu logging To configure the severity level of MWAM logging information to send to the Supervisor module, use the mwam module cpu logging command in global configuration mode. To remove this configuration, use the no form of the command.
Chapter 6 Command Reference Command Details The following example allows the Supervisor console to display debugging log messages received from processor 2 on the MWAM in slot 5: Sup-7600(config)#mwam module 5 cpu 2 logging debug Multiprocessor WAN Application Module User Guide 6-16 OL-4858-07
Chapter 6 Command Reference Command Details show logging To display the slave log options that are enabled on the MWAM, use the show logging command in privileged EXEC mode. show logging {slot slot_number | summary} Syntax Description slot_number Specifies the slot that the module is plugged into. summary Displays logging information for all MWAMs in the chassis. Defaults There are no default behavior or values. Command Modes Privileged EXEC configuration.
Chapter 6 Command Reference Command Details Field descriptions for the output of this command are listed below: Active Processor is operational and remote console/logging is active. Online Processor is operational but remote console/logging is not active. Note This state commonly occurs when a processor is not enabled by the application running on the MWAM. Inactive Processor is rest or resetting, and remote console/logging is inactive.
Chapter 6 Command Reference Command Details clear logging slot To clear the slave log options that are enabled on the MWAM, use the clear logging slot command in privileged EXEC mode. clear logging slot slot_number counts Syntax Description slot_number Defaults There are no default behavior or values. Command Modes Privileged EXEC configuration. Command History Release Modification 12.2(14)ZA4 This command was introduced. Specifies the slot that the module is plugged into.
Chapter 6 Command Reference Command Details show processor To show status information about an MWAM processor, use the show processor command available at the PC complex (processor 1 on the MWAM). show processor {processor_number | all} Syntax Description show processor Shows status information for the MWAM processor. processor_number Specifies the MWAM processor number (2-6). all Specifies all processors on the MWAM. Defaults There are no default behavior or values.
Chapter 6 Command Reference Command Details 0% CPU Utilization Messages 4115/4115 VRTC Update(s) acked by PC 244528/244528 Heartbeats(s) acked from IOS 1/1 ROMMON Config Msg(s) acked from ROMMON 0/0 Supervisor Switchover Msg(s) acked from IOS 0/0 Prepare Reload Msg(s) acked from IOS root@mwam-9# Multiprocessor WAN Application Module User Guide OL-4858-07 6-21
Chapter 6 Command Reference Command Details show log To show the upgrade or restart logs, use the show log command available at the PC complex (processor 1 on the MWAM). show log {upgrade | restart} Syntax Description upgrade Shows the upgrade log. restart Shows the MWAM and process restart log. Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.3(3)B1 This command was introduced.
Chapter 6 Command Reference Command Details reload To reload processors on an MWAM, use the reload command available at the PC complex (processor 1 on the MWAM). reload {processor processor_number | complex complex_number | all} Syntax Description processor processor_number Specifies a processor (2-6) on the MWAM. complex complex_number Specifies a complex (0, 1, 2, or all) on the MWAM. all Specifies all processors on the MWAM.
Chapter 6 Command Reference Command Details recover-ios To set the configuration register to boot with a clean configuration, use the recover-ios command available at the PC complex (processor 1 on the MWAM). recover-ios complex_number Syntax Description complex_number Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.2(9)ZA This command was introduced.
Chapter 6 Command Reference Command Details normal-ios To set the configuration register to boot with a normal configuration, use the normal-ios command available at the PC complex (processor 1 on the MWAM). normal-ios Syntax Description normal-ios Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.(9)ZA This command was introduced.
Chapter 6 Command Reference Command Details show images To list the images stored on the MWAM, use the show images command available at the PC complex (processor 1 on the MWAM). show images Syntax Description This command has no arguments or keywords. Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.(9)ZA This command was introduced. Usage Guidelines Use this command to list the image names on the MWAM.
Chapter 6 Command Reference Command Details restore To restore the previously loaded IOS image and ROM-Monitor image, use the restore command available at the PC complex (processor 1 on the MWAM). restore Syntax Description This command has no arguments or keywords. Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.3(5a)B This command was introduced.
Chapter 6 Command Reference Command Details show tech-support To display general information about the MWAM and its processors when it reports a problem, use the show tech-support command available at the PC complex (processor 1 on the MWAM). show tech-support Syntax Description This command has no arguments or keywords. Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.(9)ZA This command was introduced.
Chapter 6 Command Reference Command Details show version To display information about the currently loaded software version along with hardware and device information, use the show version command available at the PC complex (processor 1 on the MWAM). show version Syntax Description This command has no arguments or keywords. Defaults There are no default behavior or values. Command Modes PC command Command History Release Modification 12.(9)ZA This command was introduced.
Chapter 6 Command Reference Command Details mwam config-mode To set the MWAM configuration file storage mode, use the mwam config-mode command in privileged EXEC mode from the MWAM console. mwam config-mode {local | supervisor} Syntax Description mwam config-mode Sets the MWAM configuration file storage mode. local Stores configuration files locally in NVRAM of the MWAM processor. supervisor Stores configuration files in the Supervisor bootflash.
Chapter 6 Command Reference Command Details show mwam config-mode To show the MWAM configuration file storage mode, use the show mwam config-mode command in privileged EXEC mode. show mwam config-mode Syntax Description show mwam config-mode Defaults There are no default behavior or values. Command Modes Privileged EXEC Command History Release Modification 12.3(1a)BW This command was introduced. Displays the MWAM configuration file storage mode.
Chapter 6 Command Reference Command Details logging main-cpu To configure MWAM log redirection to the Supervisor for all events up to a maximum specified log level, use the logging main-cpu command in global configuration mode. To remove this configuration, use the no form of the command. logging main-cpu udp_port [log_level] [ip_addr] no logging main-cpu udp_port [log_level] [ip_addr] Syntax Description udp_port Specifies the UDP port on the MWAM for sending logs to the Supervisor.
Chapter 6 Command Reference Command Details When selecting the UDP port for an MWAM processor, you are defining a base UDP port used at the Supervisor. Two additional source ports, based on the selected port, are then automatically defined. For example, on the Supervisor you have configured the following: logging listen mwam 10000 On the MWAM, you have configured processor 2 as follows: logging main-cpu 10000 emergencies 99.99.99.
Chapter 6 Command Reference Command Details show mwam To show MWAM Transation Look-aside Buffers (TLBs) and cache errors, use the show mwam command in privileged EXEC mode. show mwam Syntax Description show mwam Defaults There are no default behavior or values. Command Modes Privileged EXEC Command History Release Modification 12.3(5a)B This command was introduced. Displays MWAM TLBs and cache errors.
Chapter 6 Command Reference Command Details 0x21480000:0x214FFFFF 0x21500000:0x2151FFFF 0x21520000:0x21527FFF 0x21528000:0x2152FFFF 0x21530000:0x21537FFF 0x21538000:0x2153FFFF 0x21540000:0x2155FFFF 0x21560000:0x2157FFFF 0x21580000:0x215FFFFF 0x21600000:0x217FFFFF 0x21800000:0x21FFFFFF 0x22000000:0x221FFFFF 0x22200000:0x2227FFFF 0x22280000:0x2229FFFF 0x222A0000:0x222BFFFF 0x222C0000:0x222DFFFF 0x222E0000:0x222FFFFF 0x22300000:0x2237FFFF 0x22380000:0x223FFFFF 0x22400000:0x225FFFFF 0x22600000:0x227FFFFF 0x22
Chapter 6 Command Reference Command Details Multiprocessor WAN Application Module User Guide 6-36 OL-4858-07
