Basic Dial NMS Implementation Guide
Task 8Using CiscoWorks 2000 Resource
Manager Essentials
About CiscoWorks 2000 RME
Cisco Works 2000 Resource Manager Essentials (CW2000 RME) is an element manager used to
routinely manage Cisco equipment.
In this case study, CW2000 RME is used for the following tasks:
Inspecting syslogs to isolate faults and device problems.
Sorting syslog messages based on device and date.
Polling for device and interface status.
Backing up and restoring Cisco IOS configurations (images and configuration files).
The following installation assumptions are made in this case study:
CW2000 maintenance release 2 has been installed on a Solaris workstation. RME version 2.2 is
available.
CW2000 is installed on the same Unix workstation as HP OpenView (HPOV).
CiscoView uses HPOV as a starting point.
Table 33 Related References and Documents
Reference URL
CiscoWorks 2000 TAC Support Page
—Provides links to
technical information for implementing, operating, and
troubleshooting Cisco Works 2000.
http://www.cisco.com/pcgi-bin/Support/
PSP/psp_view.pl?p=Software:CiscoWor
ks2000
CiscoWorks 2000 Documentation Set
—A collection of
configuration guides and reference manuals.
http://www.cisco.com/univercd/cc/td/do
c/product/rtrmgmt/cw2000/index.htm
