B-3
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Appendix B Declarations of Conformity and Regulatory Information
VCCI Statement for Japan
Caution The Part 15 radio device operates on a non-interference basis with other devices operating at this
frequency when using the integrated antennas. Any changes or modification to the product not expressly
approved by Cisco could void the user’s authority to operate this device.
Caution Within the 5.15 to 5.25 GHz band (5 GHz radio channels 34 to 48) the U-NII devices are restricted to
indoor operations to reduce any potential for harmful interference to co-channel Mobile Satellite System
(MSS) operations.
Note Dynamic Frequency Selection (DFS) operation and operation from 5500 to 5700 MHz has
not been authorized as required by the rules of the Federal Communications Commission
and is not supported until authorization is obtained.
VCCI Statement for Japan
Warning
This is a Class B product based on the standard of the Voluntary Control Council for Interference from
Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a
domestic environment, it may cause radio interference. Install and use the equipment according to
the instruction manual.
