CHAPTER
3-1
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
3
Troubleshooting Autonomous Access Points
This chapter provides troubleshooting procedures for basic problems with the autonomous access point
(model: AIR-AP1131AG or AIR-AP1131G). For the most up-to-date, detailed troubleshooting
information, refer torefer to the Cisco Technical Support and Documentation website at the following
URL:
http://www.cisco.com/en/US/products/hw/wireless/tsd_products_support_category_home.html
Sections in this chapter include:
• Checking the Autonomous Access Point LEDs, page 3-2
• Checking Basic Settings, page 3-4
• Low Power Condition for Autonomous Access Points, page 3-6
• Running the Carrier Busy Test, page 3-14
• Running the Ping Test, page 3-15
• Resetting to the Default Configuration, page 3-15
• Reloading the Access Point Image, page 3-17
• Obtaining the Access Point Image File, page 3-19
• Obtaining the TFTP Server Software, page 3-21
