2-10
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Chapter 2 Installing the Access Point
Deploying the Access Points on the Wireless Network
Figure 2-4 indicates where you should push to open and close the adjustable T-rail clips.
Figure 2-4 Adjusting the T-Rail Clips
1 Push here to open 2 Push here to close
121759
2
1
1
2
