C-2
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Appendix C Access Point Specifications
Power Output 100 mW (20 dBm)
50 mW (17 dBm)
25 mW (14 dBm)
10 mW (11 dBm)
5 mW (8 dBm)
3 mW (5 dBm)
2 mW (2 dBm)
1 mW (-1 dBm)
(Depending on the regulatory
domain in which the access
point is installed)
50 mW (17 dBm)
25 mW (14 dBm)
10 mW (11 dBm)
5 mW (8 dBm)
3 mW (5 dBm)
2 mW (2 dBm)
1 mW (-1 dBm)
(Depending on the regulatory
domain in which the access point
is installed)
Autonomous access points
50 mW (17 dBm)
30 mW (15 dBm)
25 mW (14 dBm)
10 mW (11 dBm)
5 mW (8 dBm)
3 mW (5 dBm)
2 mW (2 dBm)
1 mW (-1 dBm)
Lightweight access points
50 mW (17 dBm)
25 mW (14 dBm)
10 mW (11 dBm)
5 mW (8 dBm)
3 mW (5 dBm)
2 mW (2 dBm)
1 mW (-1 dBm)
(Depending on the regulatory
domain in which the access point
is installed)
Antenna A diversity system with two integrated 3-dBi antennas. A diversity system with two
integrated 4.5-dBi antennas.
Frequency 2.400 to 2.497 GHz
(Depending on the regulatory domain in which the access point is
installed)
5.15 to 5.25 GHz
5.25 to 5.35 GHz
5.725 to 5.85 GHz
(Depending on the regulatory
domain in which the access point
is installed)
Modulation Complementary Code Keying
(CCK)
Orthogonal Frequency Division Multiplex (OFDM)
Subcarrier modulation BPSK (1 Mbps)
QPSK (2 Mbps)
CCK (5.5 and 11 Mbps)
BPSK (6 and 9 Mbps)
QPSK (12 and 18 Mbps)
16-QAM (24 and 36 Mbps)
64-QAM (48 and 54 Mbps)
BPSK (6 Mbps and 9 Mbps)
QPSK (12 Mbps and 18 Mbps)
16-QAM (24 and 36 Mbps)
64-QAM (48 and 54 Mbps)
Data rates 1, 2, 5.5, and 11 Mbps 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
Typical indoor range 450 ft at 1 Mbps
360 ft at 11 Mbps
400 ft at 6 Mbps
100 ft at 54 Mbps
325 ft at 6 Mbps
80 ft at 54 Mbps
Table C-1 Access Point Specifications (continued)
Category
802.11g Radio Specifications
802.11a Radio Specifications802.11b Operation 802.11g Operation
