B-13
Cisco Aironet 1130AG Series Access Point Hardware Installation Guide
OL-8369-05
Appendix B Declarations of Conformity and Regulatory Information
Declaration of Conformity Statements
Annex to DofC# 441919
1. Information on Antennas and Power Levels
The AIR-(L)AP1131AG-E-K9 has integral antennas. The antenna gain is 4 dBi (for both 2.4 GHz & 5 GHz).
The maximum (conducted) power level for operation in the 2.4 GHz band and the 5 GHz band mentioned are given
below and are based on a 100 mW eirp limit applicable in the 2.4 GHz band and a 200 mW eirp limit (5150-5350
MHz) or a 1 W eirp limit (5470-5725 MHz) applicable in the 5 GHz bands.
A separate compliance document shipped with each product will correctly inform the user on the applicable
maximum power level (eirp) in his area/country, the corresponding maximum setting for the conducted power and
other restrictions that might be applicable.
Any configuration resulting in an eirp level above the regulatory limit applicable in a given country is illegal and is
outside the scope of this Declaration.
Antenna P/N Integral Ant. Gain Max Power Level
Integral antenna 2.4 GHz 4 dBi 15 dBm
Integral antenna 5 GHz 4 dBi 17 dBm
July 25, 2005
Tony Youssef
Director Corporate Compliance
