This example shows how to configure the global LLDP hold time to 200 seconds:
switch# configure terminal
switch(config)# lldp holdtime 200
switch(config)#
This example shows how to to enable LLDP to send or receive the management address TLVs:
switch# configure terminal
switch(config)# lldp tlv-select management-address
switch(config)#
Configuring Interface LLDP Commands
To configure the LLDP feature for a physical Ethernet interface, perform this task:
Procedure
PurposeCommand or Action
Enters configuration mode.switch# configure terminal
Step 1
Selects the interface to change.
switch(config)# interface type slot/port
Step 2
Sets the selected interface to either receive or
transmit.
switch(config-if)# [no] lldp {receive |
transmit}
Step 3
The no form of the command disables the LLDP
transmit or receive.
Displays LLDP configurations.(Optional)switch#show lldp
Step 4
This example shows how to set an interface to transmit LLDP packets:
switch# configure terminal
switch(config)# interface ethernet 1/2
switch(config-if)# lldp transmit
This example shows how to configure an interface to disable LLDP:
switch# configure terminal
switch(config)# interface ethernet 1/2
switch(config-if)# no lldp transmit
switch(config-if)# no lldp receive
This example shows how to display LLDP interface information:
switch# show lldp interface ethernet 1/2
tx_enabled: TRUE
rx_enabled: TRUE
dcbx_enabled: TRUE
Port MAC address: 00:0d:ec:a3:5f:48
Remote Peers Information
No remote peers exist
This example shows how to display LLDP neighbor information:
switch# show lldp neighbors
LLDP Neighbors
