CHAPTER 11
Configuring LLDP
This chapter contains the following sections:
•
Configuring Global LLDP Commands, page 127
•
Configuring Interface LLDP Commands, page 129
Configuring Global LLDP Commands
You can set global LLDP settings. These settings include the length of time before discarding LLDP information
received from peers, the length of time to wait before performing LLDP initialization on any interface, the
rate at which LLDP packets are sent, the port desription, system capabilities, system description, and system
name.
LLDP supports a set of attributes that it uses to discover neighbor devices. These attributes contain type,
length, and value descriptions and are referred to as TLVs. LLDP supported devices can use TLVs to receive
and send information to their neighbors. Details such as configuration information, device capabilities, and
device identity can be advertised using this protocol.
The switch supports the following required management LLDP TLVs:
•
Data Center Ethernet Parameter Exchange (DCBXP) TLV
•
Management address TLV
•
Port description TLV
•
Port VLAN ID TLV ((IEEE 802.1 organizationally specific TLVs)
•
System capabilities TLV
•
System description TLV
•
System name TLV
The Data Center Bridging Exchange Protocol (DCBXP) is an extension of LLDP. It is used to announce,
exchange, and negotiate node parameters between peers. DCBXP parameters are packaged into a specific
DCBXP TLV. This TLV is designed to provide an acknowledgement to the received LLDP packet.
Cisco Nexus 3000 NX-OS Layer 2 Switching Configuration Guide, Release 5.0(3)U3(1)
OL-26590-01 127
