DescriptionConvention
Nested set of square brackets or braces indicate optional or required
choices within optional or required elements. Braces and a vertical bar
within square brackets indicate a required choice within an optional
element.
[x {y | z}]
Indicates a variable for which you supply values, in context where italics
cannot be used.
variable
A nonquoted set of characters. Do not use quotation marks around the
string or the string will include the quotation marks.
string
Examples use the following conventions:
DescriptionConvention
Terminal sessions and information the switch displays are in screen font.screen font
Information you must enter is in boldface screen font.boldface screen font
Arguments for which you supply values are in italic screen font.
italic screen font
Nonprinting characters, such as passwords, are in angle brackets.< >
Default responses to system prompts are in square brackets.[ ]
An exclamation point (!) or a pound sign (#) at the beginning of a line
of code indicates a comment line.
!, #
This document uses the following conventions:
Means reader take note. Notes contain helpful suggestions or references to material not covered in the
manual.
Note
Means reader be careful. In this situation, you might do something that could result in equipment damage
or loss of data.
Caution
Related Documentation for Nexus 3000 Series NX-OS Software
The entire Cisco NX-OS 3000 Series documentation set is available at the following URL:
http://www.cisco.com/en/US/products/ps11541/tsd_products_support_series_home.html
Cisco Nexus 3000 NX-OS Layer 2 Switching Configuration Guide, Release 5.0(3)U3(1)
xii OL-26590-01
Preface
Related Documentation for Nexus 3000 Series NX-OS Software
