If you set the link to shared, STP moves back to 802.1D.
Procedure
PurposeCommand or Action
Enters configuration mode.switch# configure terminal
Step 1
Specifies the interface to configure, and enters the interface
configuration mode.
switch(config)# interface type
slot/port
Step 2
Configures the link type to be either a point-to-point link or
shared link. The system reads the default value from the
switch(config-if)# spanning-tree
link-type {auto | point-to-point |
shared}
Step 3
switch connection, as follows: half duplex links are shared
and full-duplex links are point-to-point. If the link type is
shared, the STP reverts to 802.1D. The default is auto, which
sets the link type based on the duplex setting of the interface.
This example shows how to configure the link type as a point-to-point link:
switch# configure terminal
switch (config)# interface ethernet 1/4
switch(config-if)# spanning-tree link-type point-to-point
You can only apply this command to a physical Ethernet interface.
Restarting the Protocol
A bridge running Rapid PVST+ can send 802.1D BPDUs on one of its ports when it is connected to a legacy
bridge. However, the STP protocol migration cannot determine whether the legacy switch has been removed
from the link unless the legacy switch is the designated switch. You can restart the protocol negotiation (force
the renegotiation with neighboring switches) on the entire switch or on specified interfaces.
PurposeCommand
Restarts Rapid PVST+ on all interfaces on the switch
or specified interfaces.
switch# clear spanning-tree detected-protocol
[interface interface [interface-num | port-channel]]
The following example shows how to restart Rapid PVST+ on an Ethernet interface:
switch# clear spanning-tree detected-protocol interface ethernet 1/8
Verifying Rapid PVST+ Configurations
To display Rapid PVST+ configuration information, perform one of these tasks:
PurposeCommand
Displays the current spanning tree configuration.switch# show running-config spanning-tree [all]
Cisco Nexus 3000 NX-OS Layer 2 Switching Configuration Guide, Release 5.0(3)U3(1)
86 OL-26590-01
Configuring Rapid PVST+
Restarting the Protocol
