6-24
Hardware Installation Guide for the Cisco 4451-X Integrated Services Router
OL-27644-01
Chapter 6 Installing and Upgrading Internal Modules and FRUs
Installing and Removing NIMs and SMs
Software Requirement for SMs
Cisco IOS XE software of a specified release or later release is required for using an SM.
To determine the version of Cisco IOS software that is running on your router, log in to the router and
enter the show version command:
Router> show version
Cisco Internetwork Operating System Software
4400 Software (C4400-ADVENTERPRISEK9-M), Version 12.3(8.2)T, INTERIM SOFTWARE
Locating an SM or NIM
See the “Locating Internal and External Slots for Modules” section on page 6-5 to locate the SM or NIM
slot on the motherboard.
Removing an SM or NIM
Use the following procedure to remove an SM:
Step 1 Read the “Safety Warnings” section on page 6-2 and disconnect the power supply before you perform
any module replacement.
Step 2 Access the SM slot. See Figure 6-2 for the various NIM and SM slot locations.
Step 3 Loosen the captive screws to open the slot cover. See Figure 6-8 and Figure 6-9.
Step 4 Pull the SM out of the connector on the motherboard. Keep the SM parallel with the motherboard to
prevent damage to the slot and standoff.
Step 5 Place the SM in an antistatic bag to protect it from ESD damage.
Installing an SM
To install an SM, use a number 2 Phillips screwdriver or flat-blade screw drive, and a 1/4-inch nut driver
or wrench.
Step 1 Read the “Safety Warnings” section on page 6-2 and disconnect the power supply before you perform
any module replacement.
Step 2 Identify the SM slot you will insert the SM into.
Step 3 Loosen the captive screws to open the slot cover. See Figure 6-8 and Figure 6-9.
Step 4 Insert the SM to the system board.
Note Be sure to press firmly on the SM until the board seats onto the connector.
Step 5 Insert the screws from the accessory kit through the SM into the standoffs. See Figure 6-20. Carefully
tighten the screws with a Phillips screwdriver (torque 6 to 8 in-lb or 0.7 to 1.1 Nm.).
