1-44
Cisco ONS 15454 Installation and Operations Guide
November 2001
Chapter 1 Hardware Installation
Card Installation
Step 3 Use the clips on the male AMP Champ connector to secure the connection.
The female connector has grooves on the outside edge for snapping the clips into place.
Note To install optical cable, you must first install optical cards.
1.12 Card Installation
This section describes the how to install ONS 15454 cards. The procedure for installing ONS 15454
cards is nearly identical for each card. AIC card installation is slightly different from all other cards and
is described in its own procedure. The XC/XCVT /XC10G and TCC+ installation procedures are
virtually identical and are described in one procedure. Installation for all other cards is the same and is
covered by one procedure.
The order in which you install cards is important. The proper sequence follows:
1. TCC+ cards
2. XC/XCVT/XC10G cards
3. Optical cards
4. Electrical cards
5. Ethernet cards
6. AIC card
Note Because all other cards boot from the active TCC+ card which houses the ONS 15454 software, you
must install the TCC+ card before booting any other cards. See Chapter 2, “Software Installation”
for information about the TCC+ card and software versions.
Note Before installing cards, verify that the power is turned on.
ONS 15454 cards have electrical plugs at the back that plug into electrical connectors on the shelf
assembly backplane. When the ejectors are fully closed, the card plugs into the assembly backplane.
Figure 1-29 shows card installation.
Warning
During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not
directly touch the backplane with your hand or any metal tool, or you could shock yourself.
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the
wristband cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Warning
Class I (21 CFR 1040.10 and 1040.11) and Class 1M (IEC 60825-1 2001-01) laser products.
