Cisco ONS 15454 Installation and Operations Guide
November 2001
Chapter 1 Hardware Installation
DS-1 Cable Installation
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the
wristband cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
When using DS-1 AMP Champ cables, you must equip the ONS 15454 with an AMP Champ connector
EIA on each side of the backplane where DS-1 cables will terminate. Each AMP Champ connector on
the EIA corresponds to a slot in the shelf assembly and is numbered accordingly. The AMP Champ
connectors have screw-down tooling at each end of the connector. To install an AMP Champ backplane
cover, see the “AMP Champ EIA” section on page 1-20.
Procedure: Install DS-1 AMP Champ Cables on the AMP Champ EIA
Step 1 Prepare a 56-wire cable for each DS-1 card you will install in the shelf assembly. See Table 1-5 on
page 1-41 for the ONS 15454 AMP Champ connector pin assignments.
Step 2 Connect the male AMP Champ connector on the cable to the female AMP Champ connector on the ONS
15454 backplane.
Tx Tip 5
white/slate
5 37 Tx Ring 5
slate/white
Rx Tip 5
white/slate
21 53 Rx Ring 5
slate/white
Tx Tip 6
red/blue
6 38 Tx Ring 6
blue/red
Rx Tip 6
red/blue
22 54 Rx Ring 6
blue/red
Tx Tip 7
red/orange
7 39 Tx Ring 7
orange/red
Rx Tip 7
red/orange
23 55 Rx Ring 7
orange/red
Tx Tip 8
red/green
8 40 Tx Ring 8
green/red
Rx Tip 8
red/green
24 56 Rx Ring 8
green/red
Tx Tip 9
red/brown
9 41 Tx Ring 9
brown/red
Rx Tip 9
red/brown
25 57 Rx Ring 9
brown/red
Tx Tip 10
red/slate
10 42 Tx Ring 10
slate/red
Rx Tip 10
red/slate
26 58 Rx Ring 10
slate/red
Tx Tip 11
black/blue
11 43 Tx Ring 11
blue/black
Rx Tip 11
black/blue
27 59 Rx Ring 11
blue/black
Tx Tip 12
black/orange
12 44 Tx Ring 12
orange/black
Rx Tip 12
black/orange
28 60 Rx Ring 12
orange/black
Tx Tip 13
black/green
13 45 Tx Ring 13
green/black
Rx Tip 13
black/green
29 61 Rx Ring 13
green/black
Tx Tip 14
black/brown
14 46 Tx Ring 14
brown/black
Rx Tip 14
black/brown
30 62 Rx Ring 14
brown/black
Tx Tip 15
black/slate
15 47 Tx Tip 15
slate/black
Rx Tip 15
black/slate
31 63 Rx Tip 15
slate/black
Tx Tip 16
yellow/blue
16 48 Tx Tip 16
blue/yellow
Rx Tip 16
yellow/blue
32 64 Rx Tip 16
blue/yellow
Table 1-6 Pin Assignments for AMP Champ Connectors (shielded DS1 cable) (continued)
64-Pin Blue Bundle 64-Pin Orange Bundle
Signal/Wire Pin Pin Signal/Wire Signal/Wire Pin Pin Signal/Wire
