Index
IN-11
Cisco ONS 15454 Installation and Operations Guide
November 2001
N
navigating in CTC 2-22
Netscape Communicator
obtaining
2-2
running the CTC setup wizard 2-4
Netscape Navigator
CTC browser
2-1
disabling proxy service 2-8
testing the node connection 2-6
network interface cards 2-5
networks
building circuits
6-1
default configuration see UPSR
IP networking
4-1 to 4-17
setting up basic information 3-3
SONET topologies 5-1 to 5-52
timing example 3-13
network view
description
2-15
adding nodes to map see domains
changing the background color
2-19
changing the background image (map) 2-19
creating new users 3-8
login node groups 2-15
moving node positions 2-17, 2-20
tasks 2-17
NIC 2-5
node view
description
2-14
alarm profiles, assigning 10-13
card colors 2-14
creating protection groups 3-9
creating users 3-6
setting up basic network information 3-3
setting up basic node information 3-2
setting up timing 3-14
tabs list 2-15
viewing popup information 2-15
NPJC-Pdet parameter
description
8-12
EC-1 card 8-17
OC-12, OC-48, OC-192 cards 8-39
OC-3 card 8-36
provisioning 7-21
NPJC-Pgen parameter 8-12
EC-1 card 8-17
OC-12, OC-48, OC-192 cards 8-40
OC-3 card 8-36
provisioning 7-21
O
OAM&P access 2-13
OC-N cards
BLSR trunk cards
5-11
connecting fiber 1-52
creating protection groups 3-9
data export 2-26
fiber protection 1-53
modifying transmission quality 7-18
moving BLSR trunk cards 5-24
path trace 6-12
performance monitoring for OC-12, OC-48 and
OC-192
8-37
performance monitoring for OC-3 8-33
provisioning for SDH 7-23
provision line transmission settings 7-18
provision threshold settings 7-19
timing 3-12
UPSR trunk cards 5-30
online documentation 2-4
ONS 15327 9-5
Open Shortest Path First see OSPF
optical cables see fiber-optic cables
optical carrier cards see OC-N cards
optical transmission quality
7-18
orderwire 7-29 to 7-30
