Index
IN-2
Cisco ONS 15454 Installation and Operations Guide
November 2001
viewing 10-1
wires 1-33
alarm settings
DS-1 card
7-6
DS-3 card 7-8
DS3E card 7-11
DS3XM-6 card 7-14
DS-N cards, general 7-3
EC1-12 card 7-17
Ethernet RMON thresholds 9-32
alarm suppression 10-14
alarm wires 1-33
AMP Champ EIA
attaching a ferrite
1-61
attaching DS-1 AMP Champ cables 1-43
attaching DS-1 cables 1-41
description 1-20
installing 1-24
routing cables 1-59
area range table (OSPF) 4-14
ATM 7-23
automated circuit creation 6-3, 6-6
B
backplane
BIC rear cover
1-59
connecting to PC 2-5
installing LAN wires 1-35
interface connections see backplane pins 1-32
pins see backplane pins 1-32
removing lower backplane cover 1-16
removing metal covers 1-15
backplane pins
description
1-32
alarm pins 1-33
craft interface pins 1-35
LAN 1-34
modem 1-33
TBOS 1-33
timing 1-33
X.25 1-33
baluns see electrical interface adapter
bandwidth
allocation and routing
A-2
circuit percentage used 9-30
four-fiber BLSR capacity 5-7
line percentage used 9-29
node specifications 1-64
two-fiber BLSR capacity 5-7
battery termination 1-31
Bay Assembly 1-10
Bellcore See Telcordia
BIC rear cover
1-59
bidirectional line switched ring see BLSR
bipolar violations
DS1 CV-L
8-19
DS3 CV-L 8-23, 8-26, 8-29
BITS
and BLSR setup
5-22
BITS out references 3-15
external node timing source 3-12
facilities 3-15, 3-17
pin field assignments 1-33
blades see cards
BLSR
adding a node
5-18
alarms 5-15
bandwidth capacity 5-7
choosing properties 5-14
DCC terminations 5-13
deleting circuits 5-25
enabling ports 5-13
fiber configuration example 5-11
four-fiber description 5-4
maximum node number 5-1
moving trunk cards 5-22
planning fiber connections 5-11
