B-11
Cisco ONS 15454 Installation and Operations Guide
November 2001
Appendix B Regulatory and Compliance Requirements
Installation Warnings
Qualified Personnel Warning
Invisible Laser Radiation Warning (other versions available)
¡Advertencia!
Al instalar el equipo, conectar la tierra la primera y desconectarla la última.
Varning!
Vid installation av enheten måste jordledningen alltid anslutas först och kopplas bort sist.
Warning
Only trained and qualified personnel should be allowed to install or replace this equipment.
Waarschuwing
Installatie en reparaties mogen uitsluitend door getraind en bevoegd personeel uitgevoerd
worden.
Varoitus
Ainoastaan koulutettu ja pätevä henkilökunta saa asentaa tai vaihtaa tämän laitteen.
Avertissement
Tout installation ou remplacement de l'appareil doit être réalisé par du personnel qualifié et
compétent.
Achtung
Gerät nur von geschultem, qualifiziertem Personal installieren oder auswechseln lassen.
Avvertenza
Solo personale addestrato e qualificato deve essere autorizzato ad installare o sostituire questo
apparecchio.
Advarsel
Kun kvalifisert personell med riktig opplæring bør montere eller bytte ut dette utstyret.
Aviso
Este equipamento deverá ser instalado ou substituído apenas por pessoal devidamente treinado
e qualificado.
¡Atención!
Estos equipos deben ser instalados y reemplazados exclusivamente por personal técnico
adecuadamente preparado y capacitado.
Varning
Denna utrustning ska endast installeras och bytas ut av utbildad och kvalificerad personal.
Warning
Because invisible laser radiation may be emitted from the aperture of the port when no cable is
connected, avoid exposure to laser radiation and do not stare into open apertures.
Waarschuwing
Omdat er onzichtbare laserstraling uit de opening van de poort geëmitteerd kan worden
wanneer er geen kabel aangesloten is, dient men om blootstelling aan laserstraling te
vermijden niet in de open openingen te kijken.
